Details
Parameters
Color of emission
Red (612-630 nm)
True Green (513-545 nm)
Blue (450-480 nm)
White
Electrical power
1.7
W
2.0
W
2.1
W
2.4
W
High
High
High
High
Brightness
ΦV
240
lm
IV
111
cd
ΦE
755
mW
IE
351
mW/sr
Beam angle
∢
95
°
Operating temperature
Top
min.
-40
°C
Top
max.
125
°C
Dimension
l
7.0
mm
w
7.0
mm
h
3.7
mm
Application fields
Ordering codes
| Product Type | Description | Order No. | Availability |
|---|---|---|---|
| LZ4-00MD09-0000_G2 |
|
Q65113A6761 |
Status information
Full production
Pre-production
Not planned for new design
Ordering and shipping are still possible
Discontinued
|
